Systems and Methods for Monitoring Agricultural Products and for Determining Crop Yields With High Resolution Geo-Referenced Sensors
AGERpoint®, a leading Precision Agriculture Data Analytics company centered around precise data collection and analytics, announced the issue of three additional patents by the U.S. Patent and Trademark Office. The AGERpoint patent portfolio now comprises a total of eight patents related to precision agriculture using our innovative and breakthrough technology.
The first new patent, US 10,520,482, “SYSTEMS AND METHODS FOR MONITORING AGRICULTURAL PRODUCTS” was issued on December 31st, 2019 and relates to a plant analysis system that determines spectral signatures of plants based on spectral data, and plant color based on photographic data. The spectral signatures and plant color are associated with assembled point cloud data which morphological data can be generated. A record of the plant can be created that associates the plant with the spectral signature, plant color, spectral data, assembled point cloud data, and morphological data, and stored in a library.
The second new patent, US 10,534,086, “SYSTEMS AND METHODS FOR DETERMINING CROP YIELDS WITH HIGH RESOLUTION GEO-REFERENCED SENSORS” was issued on January 14th, 2020 and relates to controlling a modular system for improved real-time yield monitoring and sensor fusion of crops in an orchard. The modular processing unit may fuse the collected data together and transmit the fused data set to a post-processing server.
The third new patent, US 10,539,545, “SYSTEMS AND METHODS FOR MONITORING AGRICULTURAL PRODUCTS” was issued January 21st, 2019 and relates to monitoring fruit production, plant growth, and plant vitality.
“We are excited to announce the expansion of our patent portfolio. We’ve spent many years innovating, including pioneering the use of Geiger Mode LiDAR and then fusing multiple data sources, to capture and uncover unique insights. We have developed the most advanced permanent crop data sensing, ML, AI and analytics platform enabled by our intellectual property.” said Andrew J. Nash, CEO of AGERpoint. He expanded with “We will continue to invest in research and development while working closely with our customers and partners as we address the data and insight needs of the scientific community to advance discovery and invention, as well as with growers and all participants in the value chain.”
Improving accuracy and timeliness of machine counting fruit
AGERpoint®, a leading Precision Agriculture Data Analytics company centered around precise data collection and analytics, announced the issue by the U.S. Patent and Trademark Office of a new, and fifth, patent on August 6, 2019 involving systems and methods for monitoring agricultural products.
The new patent, US 10,371,683, “SYSTEMS AND METHODS FOR MONITORING AGRICULTURAL PRODUCTS” relates to monitoring fruit productions, plant growth, and plant vitality. Specifically, this newest out of five patents held by AGERpoint, works to improve upon the accuracy and timeliness of machine counting of fruit on the tree or vine utilizing a data acquisition, transport, and software components.
“We are excited to continue to add to our library of patents,” said Andrew J. Nash, CEO of AGERpoint. He continued with “The ability to innovate and refine our technology sets us apart and allows us to provide extremely precise data to our partners in the value chain (food & beverage industry, growers, researchers, agronomists, insurers, industry associations, etc.).”
All About Precision: AGERpoint achieves 99% accuracy in tree counting and 95% accuracy in canopy metrics
While we pride ourselves in collecting agricultural data in a timely manner (and with less manpower) than other data collection methods, our main focus is on the accuracy of the data we collect and provide to our clients. Precision is crucial to us here at AGERpoint.
We work with clients, across multiple crop types, who use the data we collect and process for a variety of business, technical, and scientific needs. This requires our data to be precise so it can provide actionable information for our clients.
How accurate can we get?
Pretty accurate – we are able to achieve a 99% accuracy in tree counting, and can achieve a 95% accuracy in canopy metrics, such as canopy diameter, volume, density, and tree height. And if we have clear visibility of trunks, we can also achieve a 95% accuracy of truck diameter.
How do we get such precise and accurate data?
Through a combination of algorithms, QAQC using custom built tools, machine learning and classification methodologies, we are able to get the accuracy as described above. And we continue to validate and calibrate our methodologies on a regular basis for the most precise results.
QAQC Edit Process
The end-to-end AGERpoint data process includes an edit function, the QAQC Edit Process, executed by our trained Geospatial engineers and utilizing proprietary and custom AGERpoint tools. These tools allow our team to manage “outlier plants” identified by the algorithms that process the raw data we collect in the field.
Our QAQC Analyst makes visual edits using our custom tools on these rare outliers, further ensuring total data accuracy. At least ~5% of all scanned trees are sampled and visually analyzed to ensure data precision.
Field Ground Truthing
As part of AGERpoint’s standard field collection processes, we have developed reference data sets based on crop types from statistically relevant samples of trees and their associated parameters (height, trunk diameter, canopy diameter, etc.). These samples are physically measured and recorded in the field. This data is makes up the ground-truth data set used to benchmark the macro results of AGERpoint’s end-to-end data process.
We compare our collected measurements against the ground-truth data sets. The collected measurement is considered correct if it falls within a threshold of distance of the ground-truth measure (typically around 10%). Comparing our measured data to these data sets it where we are able to derive our accuracy metrics.
With over 1.5 trillion data points collected across 24 different crop types, we have a large store of historical data. This allows us to compare data sets of like crop types to ensure that what is collected is consistent across the software development process and past data collections.
With our plant matching algorithms, we are able to scan the same plants again and again to further refine the accuracy for an individual client down to the individual plant level. Over time trends or issues may be easier to spot with our data collection than with previously used methods, like manual sampling.
Our methods together are what lead to incredibly accurate data for our clients. Are you interested in learning how you could get 99% data accuracy, with less manpower? Contact us today: Sales@AGERpoint.com
We’ve added a new feature that clients who are utilizing GroveTracker data can take advantage of – MorphologyExplorer. Point Clouds are a visualization of the thousands of data points that make up an individual tree. They show extreme levels of detail of a given tree, row, or group of trees in an easy to manipulate 3D view. Now these Point Clouds can be made available as part of AGERmetrix!
Previously, our Point Clouds were separate from AGERmetrix data, but with this new tool you are able to fuse the data with Point Clouds to analyze and easily identify relationships.
Select the row you would like to inspect with the Point Cloud Select Row Tool:
This new tool will allow customers to:
- Look at a specific tree, row, or group of trees at an extremely detailed level
- Provide an angle measurement tool which is valuable for researchers running pruning and other trials
- Utilize height and width tools to measure down to the individual branch level and complete specialized measurements like stem length
- Rotate the view to inspect and identify features or issues of a specific tree
- Visualize trees before having to physically visit the field
- Continually make measurements to create a total – perfect for measuring total length of branches
All of this can be done in the field on a tablet or laptop, or from the comfort of your office.
If you’re interested in seeing your Point Clouds – reach out to us today at Sales@AGERpoint.com!
Measure trunk to trunk:
Measure trunk to branch angle:
Measure trunk from ground to first branch:
Continually measure with the Accumulation Measurement Tool for total measurements:
Multi-Year Trial Data On Individual Tree Level Demonstrated Positive Impact On Yield and Decreased Cost of Data Collection
“Utilizing AGERpoint®’s technology was really helpful in the data analysis. When you work with cutting edge growers, it is difficult to see with the naked eye ‘success’. AGERpoint® not only shows you the field improvements, but its verified in the final data. Proud to work with them.” – James Henderson, CEO, Prime Dirt, Inc.
GOAL TO EVALUATE CURRENT SOIL AMENDMENT TO VERIFY AND VALIDATE POSITIVE IMPACT ON YIELD.
Prime Dirt has been applying a soil amendment and rather than continue blindly, they’d like to confirm that this application has had a positive impact on yield.
In addition, they want to confirm they reducing the cost of data collection for field trials. Yield is measured on a per variety basis and is attributed down to each tree. This data collection has historically included a significant amount of man hours measuring each individual tree growth and monitoring harvest operations.
COLLECTED GROVETRACKER™ DATA ANNUALLY FOR OVER THREE YEARS ON 2 BLOCKS (202 ACRES AND 76 ACRES) ON A TREE BY TREE BASIS FOR A TOTAL OF 35,592 TREES.
AGERpoint® collected data points on tree height, canopy diameter, trunk diameter, canopy volume, canopy density down to the individual tree level using GroveTracker™. YieldTracker™ data was also collected during the almond harvest season by attaching the YieldTracker™ collection system to grower supplied vehicles and collecting data at the same time the windrow was being picked up from the ground.
GroveTracker™ and YieldTracker™ data was collected and specialized agronomic services were used to process and operationalize data across 3 concurrent growing years from 2016 to 2018. Post collection, the yield data is transformed into representative volume indices and matched to a give plant and its associated row within a block. Final client data is extracted from the AGERpoint®’s SaaS service and visualized into year-over-year yield graphs and maps on a variety basis.
DATA COLLECTION DEMONSTRATED A 14.6% INCREASE IN YIELD AND 2.3% INCREASE IN DENSITY OF FOLIAGE BY USING PRIME DIRT PRODUCTS.
By using AGERpoint®’s products Prime Direct was able to efficiently, and effectively, show a positive increase in both yield and density of foliage by using their products.
Historically being able to collect and analyze this much data would have been extremely time consuming and costly. Because of using AGERpoint®’s products, full data sets were able to be used instead of samples – providing incredible detailed and accurate data for decision making.
Excited to be included in Seana Day’s, from Better Food Ventures and The Mixing Bowl, AgTech Landscape 2019 in the Field Monitoring Sensors & Solutions!
GAIN THE ABILITY TO REDUCE LABOR ASSOCIATED WITH THE IDENTIFICATION, TRACKING, AND MANAGEMENT OF AREAS WITH WEEDS.
Our client needed a way to easily identify areas of poor weed control, while at the same time decreasing the labor associated in this management process. Historically this process has been a manual inspection on each row by farm employees – increasing time and cost.
In addition, they wanted to have the output (artifact) to be easily usable by farm workers on-site via a mobile device or tablet.
COLLECTED AND COMBINED GROVETRACKER™ AND AERIAL MULTISPECTRAL IMAGERY DATA TO CRATE ONE FUSED GPS ENABLED IMAGE FOR EASY NAVIGATION OF IDENTIFIED WEED AREAS.
Taking a one-time data collect with GroveTracker™ and three rounds of aerial multispectral imagery data collected over a one-year span of time, the final product was a map showing exact locations of weeds indicted by defined markers.
The defined weed markers were then categorized by how frequently they returned allowing the identification of weeds that were tolerant to the herbicide used. This categorization allowed our client to focus efforts on those areas with a more advanced weed management protocol. In the past the same weed management practice would have been applied to all weeds, resulting in poor control on herbicide tolerant weeds.
REDUCED LABOR COST BY MORE THAN 50% DUE TO THE COLLECTION, PROCESSING, AND ANALYSIS OF BOTH GROUND AND AERIAL IMAGERY DATA.
Not only was the desired result of decreased labor costs realized, the eradication of identified weed areas aided in yield management, and reduced water requirements for affected areas – furthering cost savings and revenue opportunities.
COLLECT AN EXTENSIVE AMOUNT OF DATA TO SUPPORT PRODUCT DEVELOPMENT.
Our client works daily with crop protection products and services, fertility products and services, and plant growth regulators. They run regular trials on these services and require a large data set to make decisions. They needed to be able to not only collect an incredibly large amount of data, but also reduce trial management expenses.
DATA COLLECTED USING A COMBINATION OF GROVETRACKER™ AND YIELDTRACKER™ PRODUCTS.
AGERpoint® collected data points on tree height, canopy diameter, truck diameter, canopy volume, canopy density down to the individual tree level using GroveTracker™. In addition, yield estimation on a per tree basis was also provided.
These data points were provided as a GIS formatted data file for further analysis by our client.
~30-50% DECREASE IN TIME-FRAME FOR PRODUCTS AND SERVICES DUE TO HIGHER DATA ACCURACY AND LESS REQUIRED TRIALS.
As AGERpoint® collects data on thousands of trees versus the typical process of only hundreds at best, the higher data accuracy of trials was able to give our client more confidence in their findings. This larger data set also allowed for identification of specific product characteristics as it related to tree growth.
In addition, as less trials were required for our client their management expenses for end-to-end trials were significantly reduced.
Decreased Labor Costs While Producing 95% Accuracy Level On Yield Prediction Using A Multi-year Sample Set
IMPROVE THE EFFICIENCY AND DECREASE LABOR COSTS ASSOCIATED WITH YIELD PREDICTION ON CITRUS CROPS.
The yield prediction process has historically had high labor costs due to the complexity of the data points needed to collect and analyze. Our client wanted to improve the accuracy of their yield prediction while lowering their labor costs.
DEVELOPED AN OFFLINE MOBILE MAPPING SOLUTION TO NAVIGATE TO TREES AND ACCURATELY COLLECT DATA FROM THE FIELD.
Leveraging existing GroveTracker™ data sets, an online mobile mapping solution was developed to allow low skill workers to efficiently, and accurately, navigate to specific trees and capture the data from the field directly into the mobile application.
This entered data could then be exported and the calculation of predicted yield automated.
YIELD PREDICTION 95% ACCURATE OVER A MULTI-YEAR SAMPLE SET.
Using GroveTracker™ and Volumetric methodology, the calculated yield prediction was verified to be 95% accurate over a multi-year sample set of data collected.
This allowed our client to leverage lower skilled (and lower wage) workers to collect data in the field and still receive an extremely accurate prediction. The data analysis complexity and associated effort was almost completely eliminated and allowed the data to become actionable.
In addition, the availability of multi-year data allows for the analytics to potentially quantify, measure, and improve field conditions and yield across blocks (block variability).
IMPROVE EFFICIENCY OF SCOUTING AND IDENTIFICATION OF UNDERPERFORMING TREES.
Our client was looking to make their scouting practices for insects, disease, and water issues more efficient. In addition, the goal was to be able to identify trees with issues faster than they would be manually identified.
FUSED GROVETRACKER™ AND VITALITYTRACKER™ DATA TO EASILY VIEW DATA POINTS FOR ALL TREES AT A GLANCE.
The benefit to fusion of ground and aerial data is the ability for advanced analysis of disease down to the individual tree level. In addition, the availability of year-over-year data allowed for sophisticated decision prediction and management.
EASIER, AND DOWN TO THE INDIVIDUAL TREE, IDENTIFICATION OF UNDERPERFORMANCE.
The combination of GroveTracker™ and VitalityTracker™ data via the AGERmetrix interface allowed for easy identification of problem trees with cankers and marginal leaf necrosis. This data was delivered through a mobile app to show specifically which tree had issues as shown to the right – yellow trees are the ones that need to be scouted
